Introducing the Anderson PTP Series
The Anderson PTP Series stands as the pinnacle of excellence in traditional manufacturing processes. It embodies the perfect blend of advanced technology and time-tested methods. This series is a testament to our commitment to delivering superior quality and performance in the manufacturing industry.
Excellence in Traditional Manufacturing
With a wide selection of machine configurations, we cater to our clients' diverse needs.
Key Features:
• High-Grade Components: Ensures durability and performance.
• Heavy-Duty Cast Iron Base and Gantry Construction: Provides a robust and reliable manufacturing system.
• Fully Integrated Software Package: Streamlines workflow and simplifies parts designing.
• Syntec CNC Controller: Expertly handles motion control.
Working Table 3200 mm X 1400 mm (126” x 55”)
No. Of Vacuum Fields 2 working fields
Table Style Movable Vacuum Pods & Rails
Table Size X 3200 mm (126”)
Table Size Y 1400 mm (55”)
Stroke of Z-Axis 250 mm (9.8”)
X-Drive System Helical Rack & Pinion
Y-Drive System Helical Rack & Pinion
Z-Drive System Ball Screw
Rapid Travel Speed In X 80 meters/min (3,149”/min)
Rapid Travel Speed In Y 60 meters/min (2,362”/min)
Rapid Travel Speed In Z 20 meters/min (787”/min)
Maximum Rapid Traverse 100 meters/min (3,937”/min)
Spindle Power 12 HP air cooled (18 HP optional)
Max Speed (Rpm) 21,000
Clamping System HSK-63F
Automatic Tool Changer 8 / 10 / 12 / 16
# of Pods & Rails 6 rails with 2 pods each
# of Pods per rail 3 standard 50mm thickness movable pods
# of Pop Up Pins 2 pins per rail
# of Pop Up Pins at L & R end of Machine 2 pins on Left, 2 pins on right
Panel Lifting Blades 4
Drilling/Boring Unit 3 Horsepower
Rotational Speed 4800 RPM
Vertical Drills X: 13, Y: 7
Horizontal Drills X: 3 + 3, Y: 1 + 1
Drilling Pitch 32 mm
X + Y Sawing Unit Optional
C-Axis Optional
Controller FANUC 0i + PC Front End
Weight 3,500 Kg (7,716 lbs.)
Vacuum Pump One (1) 9 HP Becker
Light Barriers 2 working zones
Backside Safety Fence Optional
