Adapter-Plates AP-S4

Description

• Specially developed Adapter-Plate for using vacuum blocks VCBL-B on console table systems from SCM / Morbidelli

• The Adapter-Plates are used on the TVN consoles of SCM/Morbidelli (console width 109 mm) and are mechanically pre-fastened to the console

• Vacuum blocks VCBL-B are placed into the suction cup mount of the Adapter-Plate at any orientation in 15° steps to orient the suction area as desired

Note - SCM/Morbidelli
SCM / Morbidelli is a registered and protected trademark. The articles listed here are products of J. Schmalz GmbH that have been designed to fit CNC machining centers from SCM / Morbidelli.

Product Highlights

• Modular system consisting of Adapter-Plate and vacuum blocks offers maximum flexibility in positioning the vacuum blocks

• Vacuum blocks of different heights allow several working heights and, depending on the machine, also 5-axis machining

• Mixed operation with Schmalz VCBL-S4 and original equipment vacuum blocks possible due to compatible heights

• Unused suction cups can be left on the machine table thanks to the touch valve
