ENTECCO E-SERIES E3215

Description

The E-Series line of dust collectors for woodworking can be installed indoors or outdoors (covered or closeted) to comply with NFPA requirements. There are four sizes available with five motors for ten different configurations.

FEATURES AND BENEFITS

• ePTFE Membrane bags for fine dust cake release – see photos on page 2
• Standard configurations ship in two weeks and set up in 15 minutes
• Patented EFlektor Baffle for excellent dust distribution
• Backward inclined fans provide more suction than competitive models
• Compact footprint is 46” wide and 6’-10” to 12’-4” long
• 5’ shipping height and 10’-9” operating height
o 8’operatingheightavailable
• Optional Vibratory Cleaning Device (adds 6” to height) aids in cleaning
• Quiet operation under 85 dBA
• Higher fabric area means suction is maintained
• FOUR discharge options:
o 45-GallonWasteBags
o 60-Gallon Totes with Casters (pictured in E2410 TT at right) o 200 to 700-Gallon Triple-Access Dump Bin
o RotaryAirlockwithchuteordroptubetorelaysystem
• Optional 2 1⁄2’ Leg Extension Kit for larger waste bags, dump bins, and airlock
• Waste Gates allow bags to be swapped while unit continues to run
• Fan motors Pre-Wired with 15’ Pigtail in 10 ga (5 to 10 hp) or 8 ga (15 and 20 hp)
• Discharge Videos Installation Videos
•Direct and Variable Frequency Drive starters available for 3-phase (460V, 230V, 208V)
o VFD includes Pressure Transducer Kit that adjusts fan speed to maintain suction
